【ePAHT-CF】 ePAHT-CF or high temperature resistant carbon fiber nylon is made of 85% nylon and 15% carbon fiber. This material has high toughness, wear resistance. Temperature resistance up to 150 °C, short-term up to 180 °C. The material is compatible with most 3D printers.
【Stable Dimensional Tolerance】Minimum tolerance and small shrinkage - ensure consistent feeding and stable prints, no clogging, extremely high printing success, resulting in printed parts that have excellent surface finish and are very accurate. (Depending on the printer)
【No knotting and clogging】 750g spool. Material with excellent circularity and very small diameter tolerance, does not overlap or tangle. It melts easily, does not crack, does not contain bubbles. Print smoothly and repeatedly without clogging the nozzle or extruder.
【Recommended printing temperature】The nozzle temperature of 260-300 °C will ensure you smooth prints without frequent calibration and less problems with the extruder.
【Vacuum Sealed Packaging】 Net material weight : 750g. eSUN filament comes sealed in a vacuum sealed desiccant bag to keep it dry and free from dust and foreign particles, prevent clogging of nozzles and provide smooth 3D models.
String diameter: 1.75 ± 0.03 mm
Coil Dimension: Diameter 200mm - Width 64mm - Center Hole 57mm
Package size: 216 x 202 x 76 mm
Package weight: 1.48 kg
Nozzle temperature: 260-300℃
Pad temperature: 80-90℃
Density: 1.24 g / cm3
Melt Flow Index: 6 (250 °C / 5 kg) g / 10 min
Tensile strength: 85 Mpa
Elongation at breaking point: 26%
Bending strength: 122 Mpa
Flexural modulus: 5160 Mpa
Notch toughness: 15.5 KJ / ㎡
Deformation temperature: 120 (°C, 0.45Mpa)
|Category:||PA - nylon|
|Color:||black, natural, s uhlíkem|
|Diameter:||± 0,03 mm|
|Bed temperature:||80 - 90°C|
