Tango v1.0 motherboard
The motherboard is the brain of the 3D printer, which is based on the AVR processor ATmega2560. Read more

Sold out

45,79 €

Producer: BIQU

Description



  • Supports 3 colors of filament. You can use a computer with a USB cable to control a 3D printer.
  • 6 input interfaces for stepper motor
  • 5 temperature sensors
  • LCD support and SD card extension for offline print
  • Using ATmega2560 as the main control chip with a high-performance USB chip on UART CP2102, compatible with all RAMPS firmware
  • Input voltage: 12-24V
  • Pwm DC output (heating bars, fans, etc.); 6 outputs (1 large current, 3 medium currents, 2 small currents), powered by high-performance MOS with low resistance, LED as an indicator for each output.



Note:

The picture is illustrative. (The color of the connector may change.)



Warning:


The product may require professional assembly, not a separate functional total.
